Wenzhou Kinee Electrical Co., Ltd. yog ib qho ntawm feem txhim khu kev qha manufacturers thiab lwm tus neeg ntawm thermomagnetic lub cev muaj zog tiv thaiv Circuit Court breaker nyob rau hauv Suav teb. Peb sov siab txais tos koj rau cov lag luam wholesale thermomagnetic lub cev muaj zog tiv thaiv Circuit Court breaker rau muag ntawm no los ntawm peb lub hoobkas. Tag nrho cov khoom customized yog nrog cov khoom zoo thiab cov nqi sib tw.
Khoom Taw Qhia
KNV2P series teb thermomagnetic lub cev muaj zog tiv thaiv Circuit Court breaker yog tsim tshwj xeeb rau cov hluav taws xob motors thiab yog siv nyob rau hauv AC 50/60Hz circuits nrog ib tug rated voltage Tsawg dua los yog sib npaug rau 690V.
Qhov no thermomagnetic lub cev muaj zog tiv thaiv Circuit Court breaker muab overload, luv luv Circuit Court, thiab theem tsis tiv thaiv, nrog rau qhov chaw tam sim no ntawm 0.1A txog 32A. Raws li lub tshuab hluav taws xob tiv thaiv hluav taws xob tiv thaiv hluav taws xob, nws yog qhov tsim nyog rau kev pib thiab kev tiv thaiv peb ntawm -theem asynchronous motors, muaj lub cev muaj zog xws li cov twj tso dej, kiv cua, thiab cov cuab yeej siv tshuab, tiv thaiv kev poob qis vim yog 5-7 npaug ntawm qhov pib tam sim no.
Qhov no thermomagnetic lub cev muaj zog tiv thaiv Circuit Court breaker kuj txhawb DIN rail mounting thiab nta phau ntawv rau / tawm ua haujlwm thiab qhov taw qhia tsis raug.
Technical Parameters
|
Parameter |
Txuj |
Chav tsev |
Tus nqi |
|
Qauv |
KNV 2 P |
||
|
Kev siv qeb |
IEC 947-2 |
A |
|
|
IEC 947-4-1 |
AC-3 |
||
|
Rated Ua Haujlwm Voltage (Ue) |
IEC 947-2 |
V |
690 |
|
Rated rwb thaiv tsev Voltage (Ui) |
IEC 947-2 |
V |
690 |
|
Rated ua hauj lwm zaus |
IEC 947-2 |
Hz |
50/60 |
|
Rated Impulse Nrog Voltage (Uimp) |
IEC 947-2 |
kV ua |
6 |
|
Total Power Dissipation per Pole |
W |
2.5 |
|
|
Mechanical life (CO: Kaw / Qhib) |
C.O. |
100000 |
|
|
Hluav taws xob lub neej ntawm AC-3 chav kawm loads |
440V / 2 |
C.O. |
100000 |
|
440v ib |
C.O. |
- |
|
|
Load Level (Max. Kev khiav hauj lwm tus nqi) |
C.O./h |
25 |
|
|
Max. Pa cua sov tam sim no |
IEC 947-4-1 |
A |
0.16...32 |
|
Rated Load |
IEC 947-4-1 |
Nruam load |
Cov lus xaiv rau Circuit Breakers rau kev tiv thaiv lub cev muaj zog
|
Hom |
Txheem ntsuas lub zog ntawm 50/60 Hz peb-theem motors hauv qeb AC-3 |
Kev hloov kho ntau yam |
|||||
|
220V |
380V |
415V |
440V |
500V |
660V |
||
|
kW |
kW |
kW |
kW |
kW |
kW |
||
|
KNV2PM01/RS01 |
- |
- |
- |
- |
- |
- |
0.1-0.16 |
|
KNV2PM02/RS02 |
- |
- |
- |
- |
- |
- |
0.16-0.25 |
|
KNV2PM03/RS03 |
- |
- |
- |
- |
- |
- |
0.25-0.4 |
|
KNV2PM04/RS04 |
- |
- |
- |
- |
- |
0.37 |
0.4-0.63 |
|
KNV2PM05/RS05 |
- |
- |
- |
0.37 |
0.37 |
0.55 |
0.63-1 |
|
KNV2PM06/RS06 |
- |
0.37 |
- |
0.55 |
0.75 |
1.1 |
1.1-1.6 |
|
KNV2PM07/RS07 |
0.37 |
0.75 |
0.75 |
1.1 |
1.1 |
1.5 |
1.6-2.5 |
|
KNV2PM08/RS08 |
0.75 |
1.5 |
1.5 |
1.5 |
2.2 |
3 |
2.5-4 |
|
KNV2PM10/RS10 |
1.1 |
2.5 |
2.2 |
3 |
3.7 |
4 |
4-6.3 |
|
KNV2PM14/RS14 |
2.2 |
4 |
4 |
4 |
5.5 |
7.5 |
6-10 |
|
KNV2PM16/RS16 |
3 |
5.5 |
5.5 |
7.5 |
7.5 |
9 |
9-14 |
|
KNV2PM20/RS20 |
4 |
7.5 |
9 |
9 |
9 |
11 |
13-18 |
|
KNV2PM21/RS21 |
5.5 |
11 |
11 |
11 |
11 |
15 |
17-23 |
|
KNV2PM22/RS22 |
5.5 |
11 |
11 |
11 |
15 |
18.5 |
20-25 |
|
KNV2PM32/RS32 |
7.5 |
15 |
15 |
15 |
18.5 |
26 |
24-32 |
|
KNV3M06 |
- |
0.37 |
- |
0.55 |
0.75 |
1.1 |
1.1-1.6 |
|
KNV3M07 |
0.37 |
0.75 |
1.1 |
1.1 |
1.1 |
1.5 |
1.6-2.5 |
|
KNV3M08 |
0.75 |
1.5 |
1.5 |
1.5 |
2.2 |
3 |
2.5-4 |
|
KNV3M 10 |
1.1 |
2.2 |
2.2 |
3 |
3.7 |
4 |
4-6 |
|
KNV3M 14 |
2.2 |
4 |
4 |
4 |
5.5 |
7.5 |
6-10 |
|
KNV3M20 |
4 |
7.5 |
7.5 |
7.5 |
10 |
11 |
10-16 |
|
KNV3M 25 |
5.5 |
11 |
11 |
11 |
15 |
18.5 |
16-25 |
|
KNV3M40 |
11 |
18.5 |
18.5 |
22 |
25 |
33 |
15-40 |
|
KNV3M63 |
15 |
30 |
33 |
33 |
40 |
55 |
40-63 |
|
KNV3M80 |
22 |
40 |
45 |
45 |
55 |
63 |
56-80 |
