Wenzhou Kinee Electrical Co., Ltd. yog ib qho ntawm feem txhim khu kev qha manufacturers thiab lwm tus neeg ntawm ac220v 3p magnetic contactor nyob rau hauv Suav teb. Peb sov siab txais tos koj rau cov lag luam wholesale ac220v 3p magnetic contactor muag ntawm no los ntawm peb lub hoobkas. Tag nrho cov khoom customized yog nrog cov khoom zoo thiab cov nqi sib tw.
Khoom Taw Qhia
KNX8C series AC contactors yog tsim rau circuits siv lub ntsuas hluav taws xob ntawm 660V AC 50/60Hz thiab cov ntsuas tam sim no mus txog 85A, rau kev tsim khoom, tawg, nquag pib, thiab tswj cov AC motors. Ua ke nrog cov pab cuam tiv thaiv, ncua sij hawm qeeb, thiab cov cuab yeej sib cuam tshuam, nws dhau los ua lub sijhawm - ncua sijhawm contactor, tus neeg saib xyuas kev sib cuam tshuam, lossis lub hnub qub -delta starter. Nrog lub thermal relay, nws tuaj yeem ua ke rau hauv lub tshuab hluav taws xob hluav taws xob. Nws ua raws li IEC 60947-1 tus qauv.
Rau cov ntawv thov uas yuav tsum tau muaj kev tswj xyuas qis dua, AC220V 3P Sib Nqus contactor variant ntawm no series muaj seamless compatibility nrog cov qauv kev lag luam tswj. Tsis tas li ntawd, AC220V 3P Magnetic contactor configuration ua kom ntseeg tau tias kev ua tau zoo hauv kev pib nquag- nres kev ua haujlwm, tshwj xeeb tshaj yog thaum ua ke nrog cov saum toj no- hais txog cov khoom pabcuam. Thaum xaiv AC220V 3P Sib Nqus contactor rau koj lub vaj huam sib luag, nco ntsoov tias nws cov coil noj tseem nyob hauv IEC txwv txawm tias nyob rau hauv cov khoom hloov pauv. Thaum kawg, AC220V 3P Sib Nqus contactor version txhawb tib lub thermal relay kev koom ua ke, ua kom tiav cov hluav taws xob hluav taws xob pib daws teeb meem rau 660V lub ntsiab circuits.
Technical Parameters
|
Hom |
KNX8C-9 |
KNX8C-12 |
KNX8C-18 |
KNX8C-22 |
KNX8C-32 |
||
|
Siv tau rau qeb AC1 lub luag haujlwm |
20A |
20A |
25A |
32A |
50A |
||
|
Siv tau rau qeb AC3 lub luag haujlwm |
200-240V |
2.5 kW/11A |
3.5kW/13A |
4.5 kW/18A |
5.5 kW/22A |
7.5kW/32A |
|
|
380-440V |
4 kW/9A |
5.5kW/12A |
7.5kW/18A |
11 kW/22A |
15 kW/32A |
||
|
500-550V |
4 kW/7A |
7.5 kW/12A |
7.5kW/13A |
15 kW/22A |
18.5 kW/28A |
||
|
690V |
4 kW/5A |
7.5 kW/9A |
7.5 kW/9A |
15 kW/18A |
18.5kW/21A |
||
|
Nruam Tam sim no Ith |
20A |
25A |
30A |
32A |
45A |
||
|
AC lub cev muaj zog |
Ib Theem |
115V |
0.5hp ib |
0.5hp ib |
1 HP |
2HP ib |
2HP ib |
|
230V |
1 HP |
2HP ib |
3HP ib |
3HP ib |
5HP ib |
||
|
Peb theem |
200V |
2HP ib |
3HP ib |
5HP ib |
7hp ib |
7.5hp ib |
|
|
230V |
3HP ib |
3HP ib |
5HP ib |
7.5hp ib |
10 HP |
||
|
460V |
2HP ib |
7.5hp ib |
10 HP |
10 HP |
20HP ib |
||
|
575V |
5HP ib |
10 HP |
15 hp cas |
15 hp cas |
20HP ib |
||
|
Hom |
KNX8C-40 |
KNX8C-50 |
KNX8C-65 |
KNX8C-75 |
KNX8C-85 |
||
|
Siv tau rau qeb AC1 lub luag haujlwm |
60A |
80A |
100A |
110A |
135A |
||
|
Siv tau rau qeb AC3 lub luag haujlwm |
200-240V |
11 kW40A |
15 KW 55A |
18.5 kW 65 A |
22 kWm 75a |
25 kW85a |
|
|
380-440V |
18.5 kW 40A |
22 kW 50A |
30 kWm 65a |
37kW75a ua |
45kW 85A |
||
|
500-550V |
22 kWm 32A |
30 kWm 43a |
37 kWm 60a |
45 kWm 64 a |
45 kW 75A |
||
|
690V |
22 kWm 25A |
30 kWm 33a |
37 kWm 47a |
45kW 47A |
45 kWm 52 a |
||
|
Nruam Tam sim no Ith |
50A |
70A |
80A |
90A |
100A |
||
|
AC lub cev muaj zog |
Ib Theem |
115V |
3HP ib |
3HP ib |
5HP ib |
5HP ib |
7.5hp ib |
|
230V |
5HP ib |
7.5hp ib |
10 HP |
15 hp cas |
15 hp cas |
||
|
Peb theem |
200V |
10 HP |
10 HP |
15 hp cas |
20HP ib |
25 hp cas |
|
|
230V |
10 HP |
15 hp cas |
20HP ib |
25 hp cas |
30 hp cas |
||
|
460V |
25 hp cas |
30 hp cas |
40 hp cas |
50HP ib |
50HP ib |
||
|
575V |
25 hp cas |
30 hp cas |
40 hp cas |
50HP ib |
50HP ib |
||
Cim npe nrov: AC220v 3p magnetic contactor, Tuam Tshoj ac220v 3p magnetic contactor manufacturers, lwm tus neeg, Hoobkas
